Induction Silver Melting Furnace

Technical Specification Rated Voltage : 415 V AC 50 HZ Electrical Installation : Three Phase Rated Power : 15 KW to 30 KW Crucible Capacity : 10 KG to 30 KG Crucible Material : Graphite Maximum Temperature : 1200°C Temp. Measurement : K Type Melting Time : 15 – 30 Min Water Cooling System : Chilling Unit Water Pressure : 2 Bar Cooling Water Temperature : 20°C – 30°C Water Flow : 20 LPM Net Weight (with Chilling Unit) : 220 KG Dimensions (mm) – L × B × H Induction Panel : 660 × 840 × 965 Chilling Unit : 740 × 585 × 990 Tilting Unit : 690 × 610 × 890 Features Solid State IGBT Technology Perfect Homogenous of Alloys Easy & Quiet Operation Ideal for Melting Gold & Silver Less Power Consumption Increased Productivity Low Maintenance Trip & Failure Display Environment Friendly Operation Compact Design Heavy Duty Gear Type Tilting Unit Automatic Power & Temp. Control Application Jewellery Work Shop Gold / Silver Casting Gold / Silver Refining Hall Marking Centers Bullion Chain & Bangle Making Retail Showrooms Leb & Research Institute
